DJI RS 4 Handheld Camera Gimbal Stabilizer

DJI RS 4 Handheld Camera Gimbal Stabilizer

The DJI RS 4 Handheld Camera Gimbal Stabilizer is a versatile and durable Camera handling gimbal intended for professional videographers and photographers. It has several accessory ports, such as 1/4″-20 mounting holes, a cold shoe, Ronin Series Accessories (RSA)/NATO connectors, and several USB-C ports for focus motor communication, video transmission, and RSS camera control. The gimbal is powered by a 3000 mAh LiPo 2S battery (BHX711-3000-7.2V), which can run the device for up to 12 hours under ideal circumstances and takes about 2.5 hours to fully charge using an 18W fast charger. The Bluetooth 5.1 of the DJI RS 4 Camera Gimbal Stabilizer guarantees a smooth connection with the Ronin app, which works with iOS 11.0 and Android 8.0 or later. With a tested payload capacity of 3 kg (6.6 lbs) and a maximum regulated rotation speed of 360°/s across the pan, tilt, and roll axes, the DJI RS 4 Camera Gimbal Stabilizer has remarkable operational performance.

A roll axis from -95° to +240°, a tilt axis from -112° to +214°, and a pan axis of 360° continuous rotation are all possible within the mechanical range. The gadget runs efficiently between -20° and 45° C (-4° to 113° F), with a frequency range of 2.400-2.4835 GHz. The Bluetooth transmitter power is less than 8 dBm. The gimbal is enhanced by the DJI Ronin Image Transmitter, which has an HDMI port, an RSS camera control port, a power/communication port, and an extension cold shoe. The stabilizing gimbal for the DJI RS 4 has 126 g in weight and 82×63×24 mm in size, and it operates on two frequency bands (2.400-2.4835 GHz and 5.725-5.850 GHz). With extra parts like the grip, extended grip/tripod, and quick-release plates, the gimbal’s total weight comes to about 1066 g (2.35 lbs). When unfolded, its dimensions are 370×191×189 mm, while its folded measurements are 245×255×75 mm.

2nd-Gen Native Vertical Shooting

With its newly built horizontal plate, the DJI RS 4 Camera Gimbal Stabilizer allows for faster and easier operation with second-generation native vertical shooting. You can easily transition to vertical shooting by just releasing the horizontal plate and locking it into the vertical position, all without the need for other attachments. The DJI RS 4 gives you the ability to use a joystick to modify the lens zoom or a dial to control the focus when used in conjunction with the new DJI Focus Pro Motor. Effective lens control is made possible by its seamless functioning.

2nd-Gen Automated Axis Locks

The automated axis locks greatly improve shooting, transition, and storage efficiency by enabling RS 4 to rapidly begin operating or go into sleep mode. To further lessen gimbal wobble, the axis locks have narrower gaps when they are locked. The DJI RS 4 Gimbal Stabilizer offers enhanced performance that increases the efficiency of solo creation while supporting the professional-grade capabilities of DJI PRO products.
